DIMENSIONS
Length: 71 inches Width: 18 inches Height: 34 inches
Wheelbase: 65 inches
WEIGHT
220 lb. (with battery), 395 lb with driver
FRAME
Size of tubing: 3/4 and 1 inches .065 walls
Type of tube: Mild steel
Controller type: Curtis PMC model 1204-102
Input voltage: 24-36 volts
Current limit: 275 amps
1 hour rating: 75 amps
Curtis 900R Battery Gauge
Dual Volt/Amp Meter
Diameter rear wheel: 20"
Drive train type: #219 chain
Gear ratio: 6 to 1
Motor type: Permag 4-pole brush type
Rated speed: 3000 RPM
Rated voltage: 24 vdc
Cont. power: 1.0 hp
Cont. current: 41 amps
Peak power: 3.5 hp
Peak current: 175 amps
Weight: 15 lbs
Battery type: Trojan Pacer 22 NF lead acid
Cell voltage: 2 volts
Number of cells per battery: 6
Number batteries in system: 2
Diameter of front wheel: 20 inches
Suspension: Double A-Arm
Steering Type: Go-cart type
Brakes type: Drum (tandem bicycle)
