DIMENSIONS
Length: 137 in. Width: 36 in. Height: 33 in.
WEIGHT
160 lbs. w/o battery & driver
WHEELBASE: 80 in. Track (Front): 27.5 in.
Ground Clearance: 3 in.
Suspension: Coilover with unequal length A arm in front
Trail link in rear
Steering: Rack and pinion
Wheels: Aluminum NGM, 14 in.
Brakes: Wilwood disc brakes
Tires: Bridgestone 18.5 in., 120 PSI
12 Panasonic LC-RA1212P1 rechargeable lead-acid batteries in series
Voltage: 96 volts
Capacity: 12 Ah / 20 hours
Weight: approx. 64 lbs
Manufacturer: New Generation Motors SC-M150-08
Weight: 20 kg
Type: Axial flux DC brushless permanent magnet wheel motor
Bus Voltage Range: 84-108 volts
Maximum Speed: 1250 rpm
Power Output: 9.0 kW
Horsepower: 12 hp
Efficiency: approx. 92 %
Motor Controller: New Generation Motors EV-C200, approx. 92% efficiency, with regeneration
Cell Manufacturer: Siemens, Inc.
Cell Type: Monocrystalline
Cell Size: 10 cm x 10 cm, 100 cm2
Cell Efficiency: 14.5%
Array Size: 0.9 square meters
Array Power Output: approx. 60 watts
Power Tracker: Solectria Boost converter
