DIMENSIONS
Length: 118 in. Width: 36 in. Height: 29 in.
WEIGHT
Total weight: 400 lbs. Body: 29 lbs.
CHASSIS
3/4 in. mild steel round tube 0.05 wall
Manufacturer: Panasonic
Model: LCR6V12P (16-6V batteries, 96V system)
Type: lead-acid
Capacity: 1.15 kWh discharge rate at 20 hr
Weight: 1.3 lbs per battery (0.6 kg)
Total weight: 21.2 lbs (9.6 kg)
Motor Manufacturer: Kollemorgen / Industrial Drive
Model: TM-2952-3133-B
Weight: 14.5 lbs (6.6 kg)
Power Output: 746 W
Maximum speed: 3600 rpm
Composite construction vacuum bag wet lay-up process
Fiberglass (exterior) - Plexiglas canopy shield
Fiberglass/matt (interior) - foam core
Front Suspension: Double rubber isolators
Rear Suspension: Rock Shock Super Deluxe
Wheel Type: NewGen one-piece CNC-machined from aluminum billet
Brake Manufacturer: Hayes mountain bike
Brake Type: Dual Piston Hydraulic Disc Brakes (2)
Tire Manufacturer: Bridgestone / Firestone
Tire Type: Solar tires (3) at 120 PSI
